ANCHOR 2600

The ANCHOR 2600 is opened and closed by turning the input unit. A spindle connects the Lock to the input unit, which transmits the movement. The position of the input unit immediately indicates whether the Lock is open or closed.

Features
Codes / Functions
Article overview
Input units
Downloads


Bolt drive	Direct drive by manually turning the input unit
Bolt design	Deadbolt with 2 holes, tombac
Fastening	Standard mounting dimensions, 3 screw-on points
Installation positions	Right / Left / Top / Bottom
Drill protection	Integrated
Interfaces	1 analog / 1 digital
Plug connection	Molex PICO-SPOX
Power supply	- Battery operation - External operation, e.g. via intruder alarm system (prerequisite: PrimorSIGNAL / PrimorSIGNAL+ signal box)

ANCHOR 2600

- Ideal for small secure storage units thanks to its slim design: reduced height, recessed screw heads and narrow bolt
- Bolt made of hard-wearing tombac for the heaviest loads
- Integrated drill protection

ANCHOR 2600
User codes	9
Master codes	1
Instant opening code	✓
Operating lock	✓
False code lock	✓
4-eyes principle	✓
Opening delay time	1 - 99 min
Opening hours	1 - 19 min
Silent alarm*	✓
Remote lock*	✓
Audit - with date and time**	60
Battery monitoring	✓

* Prerequisite: PrimorSIGNAL / PrimorSIGNAL+ signal box
** Requirement: AnchorSELECT software (available in downloads from 01/2024) and DataCONNECT interface cable

Item number	Article description
A-2600-00-00	Lock ANCHOR 2600, system cable
Z-002	Square spindle, 51 mm
Z-003	Square spindle, 160 mm
Z-004	Square spindle, 240 mm
Z-005	Square spindle, 1,000 mm
Z-006	Spindle round, 51 mm
Z-007	Spindle round, 160 mm
CABLE-SET-DC	DataCONNECT interface cable set
P-SIGNAL	PrimorSIGNAL signal box, Y-adapter, system cable
P-SIGNAL-PLUS	PrimorSIGNAL+ signal box, system cable
